Pressure Transmitter

• Pressure Ranges from 1 to 600 bar
• SS body & wetted parts SS 316
• Output: 4 – 20 mA DC 2 wire
• Supply: 10 -30 VDC
• Zero/span adjustments
• Temperature Limit: -25 to + 100 Deg C
• Connection: ½” BSP (M) bottom
• Protection: IP65

We are suppliers of high-quality Baumer Pressure Transmitter for Water , air, hydraulic applications .

BaumerSanitory Pressure Transmitter.
Model : PBMN, PBSN+DH

Features:

• 3-A sanitary standards, FDA-compliant, EHEDG-certified
• Resistant to all common CIP cleaning media
• SIP-capable (150 °C max, < 30 min)
• Versions available for high media temperatures (200 °C)
• Threadless mounting using a clamping connection
• Optionally available with switching output
• Tank linearization and volume calculation
• Absolute pressure, relative pressure and vacuum measurement
•

• Application:

Food, Beverage, Biotechnology, Pharmaceutical, Measuring principle, Piezoresistive silicon sensor.

• Reference accuracy of calibrated span including the effect of zero-based linearity
• Hysteresis repeatability: ±0.075% of span
• Linear/square root programmable
• Current output
• Rangeability: Turn down ratio 100:1
• Standard process connection available
• Standard electrical connection available
• Digital Indicator
• Mounting Bracket: L/Flat type

Electronic Pressure Transmitter

Introduction:
Baumer's electronic pressure transmitters and pressure switches prove their precision and reliability every single day in thousands of applications. Whether for high-speed applications in plastic injection molding machines or in food processing production or for heavy-duty use in the petroleum industry. Our customers have already been relying on this for decades.

• Robust stainless steel housing
• Compact design
• Fully welded, dry measuring cell
• E1 approval for mobile hydraulics
• Relative pressure measurement
• Pressure measuring ranges 0 ... 25 bar up to 0 ... 1000 bar

Intrinsically Safe Pressure Transmitter

Features:

• Measurement of vacuum, absolute or gauge pressure
• Instrument as standard (±10% of range)
• Welded construction – reinforced product
• Modularity of electrical and hydraulic connections
• Highly resistant to severe process conditions (≥ 107 pressure cycles)
• Marine version (Bureau Veritas Marine)LCIE 02 ATEX 6133X
• Measuring Rage : 0 25 Mbar.....0....600 Bar
• Connection : 1/2" BSP (M)

• Reference accuracy of calibrated span including the effect of zero-based linearity
• Hysteresis repeatability: ±0.075% of span
• Linear/square root programmable
• Current output
• Rangeability: Turn down ratio 100:1
• Standard process connection available
• Standard electrical connection available
• Digital Indicator
• Mounting Bracket: L/Flat type

• Ranges: 0.1 to 5 in w.c.(Bi-directional available)
• Wetted Materials: Consult factory
• Comp. Temp. Limits: N/A
• Oper. Temp. Limits: 20 to 120◦F(-7to 49◦C)
• Process Connection: 1/8” ID rubber tubing
• Enclosure rating: N/A
