Other Details:

• Light source Pulsed Pin Point LED
• Sensing distance Tw l60 … 400 mm
• Sensing range Tb 30 … 400 mm
• Power on indication LED green
• Light indicator LED yellow
• Sensing distance adjustment qTeach / external
• Wave length 630 nm
• Suppression of reciprocal influence Yes
• Alignment optical axis 1 Degree

Article no.: 11157800

• Diffuse sensors with intensity difference
• intensity difference
• < 800 mm
• pulsed infrared diode
• PNP
• potentiometer, 270°
• connector M12 4 pin
• -25 … 55 °C
• IP 67

Baumer Make Proximty Sensor
Model : IGYX18P17B3/L
Sensing distance: 8mm
Type : M-18,PNP-NO
With 2 Mtr Cable

General data:mounting type quasi shieldednominal sensing distance Sn 8 mmassured sensing distance Sa 6,4 mmtemperature drift ± 10 % of Sr (0 ... +60 °C)hysteresis 3 ... 20 % of Sr

Electrical data:switching frequency < 400 Hzvoltage supply range +Vs 10 ... 30 VDCcurrent consumption max. 15 mAvoltage drop Vd < 2,5 VDCoutput current < 200 mAshort circuit protection yesreverse polarity protection yes

Other Details:

• Diffuse sensors with background suppression type background suppression light source pulsed red LED
• Sensing Distance Tw 30 ... 300 mm
• Sensing Range Tb 15 ... 300 mm
• Power on indication LED green light indicator LED yellow sensing distance adjustment qTeach / 1-Step Teach-in wave length 630 nm suppression of reciprocal yes alignment optical axis < 3°

light source pulsed red LEDsensing distance Tw 30 ... 300 mmsensing range Tb 15 ... 300 mmlight indicator LED yellowsensing distance adjustment qTeachwave length 630 nmsuppression of reciprocal yesalignment optical axis < 3°

Through beam sensorsOR18.TI-ZZZZ.71CVArticle no.: 11157823

• Through beam sensors
• emitter
• through beam sensor
• 13 m
• pulsed infrared diode
• cable 4 pin, 2 m
• -25 … 55 °C
• IP 67

We are engaged in offering Baumer Proximity Sensor to our clients. Our range of products is appreciated by our clients.

• Sensing Distance: 2mm,4mm,8mm,12mm,15mm....
• With Cable to connetor Version
• PNP/NPN NO NC outputs
